awaBerry | Automation Settings

Configure how Smart Automation publishes project result pages, including folder copy and S3 upload options.

Automation Settings

Summary

The Automation Settings screen controls how Smart Automation publishes portal result pages after each project execution. You can enable automatic publication and choose between copying output to a local folder or uploading it to an S3-compatible storage server. These settings apply globally to all Smart Automation projects on the connected device.

Automation Settings — initial state

Screen on arrival

Features

  • AppBar "Smart Automation Settings" — close button (X) dismisses the screen and returns to the Project Overview.
  • "Publish Portal Page" Switch — when enabled, the framework publishes an HTML portal page after each project update or execution run. When disabled, no publication occurs regardless of the method selected below.
  • Publication Method (radio buttons) — selects where the portal page is sent:
    • Copy to folder — writes the portal HTML to a local folder on the device.
      • Folder path TextField (placeholder "Enter folder path") — the absolute path on the device where files are copied.
    • Upload to storage server — transmits the portal HTML to a remote S3-compatible storage endpoint.
      • Storage path TextField (placeholder "Enter path on storage server") — the bucket/key prefix on the storage server.
      • "Edit S3 Settings" button — opens the SetupS3Storage popup for configuring bucket name, region, access key, and secret key.
  • "Save Settings" ElevatedButton — persists all settings to the device backend. Shows "Saving…" with a CircularProgressIndicator while the request is in-flight.

Scenarios

Enable portal publication to a local folder

  1. Open Automation Settings from the gear icon on the Project Overview screen.
  2. Toggle Publish Portal Page on.
  3. Select the Copy to folder radio option.
  4. Enter the full path of the destination folder in the Folder path field (e.g. /home/pi/portal).
  5. Tap Save Settings.

Enable portal publication to S3

  1. Toggle Publish Portal Page on.
  2. Select the Upload to storage server radio option.
  3. Enter the target path/prefix in the Storage path field.
  4. Tap Edit S3 Settings and fill in the bucket name, region, access key, and secret key in the popup, then confirm.
  5. Tap Save Settings.

Disable publication

  1. Toggle Publish Portal Page off.
  2. Tap Save Settings. No portal output will be generated on subsequent runs.
